Halex 3/8 in. 90-Degree Flexible Metal Conduit (FMC) Connector

Item # 100212971 | Halex Part # 91100 | UPC Code 051411911003 | UNSPSC Code 39131706 | Catalog Page #1114
Add to Favorites List Add to Customized Product Offering Remove From Customized Product Offering Add To Bin Labels Added to Bin Labels. Click icon to print Bin Labels. Add To Custom Catalog Added To Custom Catalog. Click icon to print Custom Catalog. Email Print

Product Overview

Bond flexible metal conduit (FMC) to a steel outlet box or other metal enclosure with this 3/8 in. 90 degree Flex Connector. The Tri Drive screws are compatible with Phillips, slotted and square screwdrivers. This connector meets UL and CSA requirements.

  • Connects and bonds FMC and armored cable to metal enclosures
  • Body and locknut made of high-strength, corrosion-resistant zinc alloy
  • Screw and clamp made of galvanized steel
  • Fits in a standard 1/2 in. knockout
  • Tri-drive screw head is compatible with Phillips, slotted and square screwdrivers
  • UL and CSA Listed
  • Reversible locknut designed to cut through protective coatings on boxes and enclosures to ensure ground continuity
  • For indoor use only

Specifications

Certifications and Listings
CSA Listed, UL Listed
Fitting Type
Connector
Indoor/Outdoor
Indoor, Outdoor
Manufacturer Warranty
None
Material
Steel
Pack Size
1
Product Length (in.)
2
Product Weight (lb.)
0.088
Product Width (in.)
1.81
Trade Size (in.)
3/8

Warranty

None
