Norton 1601 Series Grade 1 Size 1 to Size 6 Sprayed Black Finish Non-Handed Hold Open Arm Surface Door Closer

Item # 316650073 | Norton Part # 1601H 693 | UPC Code 840067681312 | UNSPSC Code 31162800
Add to Favorites List Add to Customized Product Offering Remove From Customized Product Offering Add To Bin Labels Added to Bin Labels. Click icon to print Bin Labels. Add To Custom Catalog Added To Custom Catalog. Click icon to print Custom Catalog. Email Print

Product Overview

The 1600 Series door closers offer proven quality, performance and reliability unmatched by the competition. A staple in the industry, these ANSI/BHMA Grade 1closers are designed for exterior or interior doors. A full complement of regular and heavy-duty arms, brackets and options make the 1600 Series closers ideal for virtually any medium traffic, commercial application.

  • Grade 1 surface door closer
  • Hold open arm
  • Friction hold-open
  • Size 1 to size 6
  • Tri mount
  • Non-handed
  • 851 degree to 10 degree swing
  • Less cover
  • Aluminum body
  • 1-3/8 in. piston diameter
  • Includes self drilling screws
  • ANSI A156.4, Grade 1, ANSI A117.1, UL Listed
  • 15-year warranty

Specifications

Brand Compatibility
Universal
Builders Hardware Product Type
Door Closer
Certifications and Listings
ANSI Certified
Color
Sprayed Black
Commercial/Residential
Commercial
General Color Family
Blacks
General Material
Brass
Hardware Finish Family
Black
Manufacturer Warranty
15 Year Warranty
Maximum Door Range (deg.)
110
Mounting
Top Mount
Product Depth (in.)
12.5
Product Height (in.)
3.5
Product Width (in.)
5

Warranty

15 Year Warranty
