Product Overview

• Equipment should be sized, selected and installed by a qualified professional to ensure proper installation, safe operation, adherence to federal, state and local codes and for valid warranty; see installation guide for more details
• Professional installation recommended
• 16 SEER Split System Heat Pump
• High-efficiency scroll compressor
• SmartShift technology to ensure quiet reliable defrost
• Factory-installed bi-flow liquid-line filter drier
• Factory-installed suction-line accumulator
• Factory-installed compressor crankcase heater
• Factory-installed high-capacity muffler
• High- and low-pressure switches
• Service valves with sweat connections and easy access to gauge ports
• Copper tube/enhanced aluminum fin coil
• Fully charged for 15' of tubing length
• Contactor with lug connection
• Ground lug connection
• AHRI Certified; ETL Listed
• Goodman brand sound control top design
• Steel louver coil guard
• Heavy-gauge galvanized-steel cabinet
• Attractive Architectural Gray powder-paint finish with 500-hour salt-spray approval
• Top and side maintenance access
• Service ports and controls are accessible while unit is operating
• When properly anchored, meets the 2010 Florida Building Code unit integrity requirements for hurricane-type winds (Anchor bracket kits available.)
• Cooling Capacity (BTU/h): 36000
• SEER/EER: 16/13
• Min. Circuit Amps: 19.1
• Max Fuse Size: 30
• Voltage: 197/253
• Liquid Line Size (IN): 3/8
• Suction Line Size (IN): 7/8
• Dimensions (WxDxH)

Specifications

Warranty

3 years
