Diversitech Oval Motor Run Capacitor 12.5 MFD, 370 VAC

Item # 789450 | Diversitech Part # 37125H | UPC Code 095247413119 | UNSPSC Code 32121500
Add to Favorites List Add to Customized Product Offering Remove From Customized Product Offering Add To Bin Labels Added to Bin Labels. Click icon to print Bin Labels. Add To Custom Catalog Added To Custom Catalog. Click icon to print Custom Catalog. Email Print

Product Overview

Motor run capacitor are used for heavy duty continuous applications such as furnace blower and condenser fan motors. Capacitors can hold a charge for long periods of time. To prevent shock the capacitor should be discharged before it is removed.

  • Guaranteed for 10,000 hours of life under normal operating conditions
  • Applied Standards: UL-810; CSA22.2 No190, IEC60252
  • Capacitance tolerance is +/-5%
  • Permissible temperature range of -40 degree C to +70 degree C
  • Individually packaged
  • Oil filled; non PCB
  • Designed with 1/4 quick connect terminals

Specifications

Brand/Model Compatibility
Most
Capacitor Type
Motor Run
Case Material
Metal
Color
White
Height
1.4 in.
HVAC Product Type
HVAC Part
Manufacturer Warranty
STANDARD
Maximum Temperature Range
70 deg. C
Microfarad Rating
12.5
Minimum Temperature Range
-40 Degrees C
Number of Phases
Single Phase
Overall Shape
Oval
Pack Size
1
Product Depth (in.)
3.6
Product Height (in.)
1.4
Product Weight (lb.)
.29
Product Width (in.)
2.1
Width
2.1 in.

Warranty

STANDARD
